Moog ACV with CANopen bus interface 7 Servo valve functions
Control modes
B99224-DV018-D-211, Rev. A, October 2018 135
7.1.12 p/flow control
The p/flow control mode is selected by setting the parameter <ControlMode> (0x6043) to 14 (p/flow control).
Figure 54: p/flow control
7.1.13 Sample frequency
The <BasicSampleFrequency> (0x3030) is the frequency of the real time control loop. With this frequency the
actual spool position is calculated from the LVDT signal and, i.e. the current controller, pressure controller and
spool position controller are calculated.
Axis position
controller
<PosControllerOutput>
(0x550F)
Transducer
interface
Any signed
16 bit / 32 bit
param. from the
object dictionary
<ActualValue1...8>
(0x6210...0x6217)
Only one signal will be routed depending on the
<ControlMode> (0x6043)
Axis velocity
controller
<VelControllerOutput>
(0x5519)
Transducer
interface
Encoder input
<ActualValue1...8>
(0x6210...0x6217)
Flow
controller
<FlwControllerOutput>
(0x520F)
Transducer
interface
Analog inputs
<ActualValue1...8>
(0x6210...0x6217)
<EncoderInput>
(0x5613)
T
P
B
A
<ActualValue1...8>
(0x6210...0x6217)
<PrsDemandValue>
(0x6390)
<SplDemandValue>
(0x6310)
<DemandValuePilot>
(0x3300)
Flow /
pressure (p)
Switchover
s
u
Actual value
transducer
interface
Pressure
demand value
generator
#PressureSetpoint#
Spool position
demand value
generator
Pressure
controller
<PrsControllerOutput>
(0x2418)
Pressure
demand sign
Spool position
controller
Analog inputs
s
u
p
u
p
u
p
u
v
u
p
u
p
u
p
u
Axis position
demand value
generator
#AxisPositionSetpoint#
<VelocityDemandValue>
(0x5615)
<FlowDemandValue>
(0x5213)
<PosDemandValue>
(0x6610)
Axis velocity
demand value
generator
Flow
demand value
generator
#AxisVelocitySetpoint##FlowSetpoint#
 Chapter 7.12
 Chapter 7.11
 Chapter 6.3
 Chapter 6.4
 Chapter 7.2
 Chapter 7.3
 Chapter 7.4
 Chapter 7.4.6
 Chapter 7.5
 Chapter 6.3
 Chapter 6.4
The signal #PressureSetpoint# is an internal signal only. It links the signal from the pressure set-
point value path to the pressure demand value generator.
 Chapter "6.2.4 Pressure setpoint value path", page 61
The signal #FlowSetpoint# is an internal signal only. It links the signal from the flow setpoint value
path to the flow demand value generator.
 Chapter "6.2.7 Flow setpoint value path", page 70
