Moog ACV with CANopen bus interface 7 Servo valve functions
Pressure setpoint conditioning / demand value generator
B99224-DV018-D-211, Rev. A, October 2018 162
7.4.4.2 Object 0x63A3: Offset
This parameter is the offset of the linear output function.
 Chapter "2.4.3 Units and prefix parameter", page 12
7.4.5 Ramp
The ramp function limits the slew rate of the input signal. The <Type> (0x63B0) parameter is used to activate
a one-quadrant, two-quadrant or four-quadrant ramp or to deactivate the ramp function.
If the ramp function is running or the ramp function is stopped by the bit 15 (ramp stop) of the #ControlWord#
signal the following <StatusWord> (0x6041) bits are set:
 Chapter "5.2.3 Object 0x6041: Status word", page 52
 Chapter "5.1.1 Object 0x604F: Local", page 43
 Chapter "5.1.2 Object 0x6040: Control word", page 44
 Chapter "5.1.3 Object 0x4040: Local control word", page 45
Figure 74: Ramp function
ValvePressureControl_DemandValueGenerator_Scaling
Index Sub-index Parameter name Data type Access
Per-
sistence Value range Default
0x63A3 1 Offset INT16 rw Y INT16 0
0x63A3 2 Unit UINT8 ro - UINT8 0
0x63A3 3 Prefix INT8 ro - INT8 0
<StatusWord> (0x6041) bit Description
9 This bit is set if the following conditions are true:
Spool position and/or pressure ramp function is active and
spool position and/or pressure function is running and
#ControlWord# bit 15 is set to false.
15 This bit is set if the following conditions are true:
Spool position and/or pressure ramp function is active and
#ControlWord# bit 15 is set to true
<StatusWord> (0x6041) Bit 9: Ramp running
<StatusWord> (0x6041) Bit 15: Ramp frozen
#ControlWord#
Bit 15: Ramp stop
Pressure
ramp
input output
Parameters
<Type>
(0x63B0)
