Moog ACV with CANopen bus interface 7 Servo valve functions
Data logger
B99224-DV018-D-211, Rev. A, October 2018 258
7.17.4.5 Object 0x318B: Trigger slope
The <TriggerSlope> (0x318B) defines the edge of the signal which starts the sampling procedure.
Value description
7.17.4.6 Object 0x318D: Trigger position
The <TriggerPosition> (0x318D) is provided as number of samples which shifts the starting point in the ring
buffer.
Value description
DataLogger
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x318B 0 TriggerSlope UINT8 rw Y 1…3 1
<TriggerSlope> Description
1 Rising (trigger on a rising edge).
2 Falling (trigger on a falling edge).
3 Both (trigger on both, rising or falling edge).
Table 108: Possible values of parameter <TriggerSlope> (0x318B)
DataLogger
Index Sub-index Parameter name Data type Access Persistence Value range Default
0x318D 0 TriggerPosition INT32 rw Y INT32 0
<TriggerPosition> Description
> 0 Post trigger.
= 0 No delay.
< 0 Pre trigger.
Table 109: Possible values of parameter <TriggerPosition> (0x318D)
