Moog ACV Series - Object 0 X6390: Demand Value; Object 0 X6391: Reference Value

Moog ACV with CANopen bus interface 7 Servo valve functions
Pressure setpoint conditioning / demand value generator
B99224-DV018-D-211, Rev. A, October 2018 159
7.4.1 Object 0x6390: Demand value
The demand value indicated by this parameter is generated from the #PressureSetpoint# by means of the
functions in the demand value generator and forwarded to the pressure controller.
 Chapter "2.4.3 Units and prefix parameter", page 12
7.4.2 Object 0x6391: Reference value
The reference value is the value that corresponds to 100 % of the input signal. This means that a 100 % pres-
sure input signal is equal to 16384 increments and a –100 % input signal is equal to –16384 increments. This
parameter depends on the controller hardware. It can be used by the field bus master to scale the setpoint
values.
 Chapter "2.4.3 Units and prefix parameter", page 12
ValvePressureControl_DemandValueGenerator
Index Sub-index Parameter name Data type Access
Per-
sistence
Value
range Default
0x6390 1 PrsDemandValue INT16 ro N INT16 None
0x6390 2 Unit UINT8 ro - UINT8 0
0x6390 3 Prefix INT8 ro - INT8 0
ValvePressureControl_DemandValueGenerator
Index Sub-index Parameter name Data type Access
Per-
sistence
Value
range Default
0x6391 1 PrsReferenceValue INT16 ro - INT16 16384
0x6391 2 Unit UINT8 ro - UINT8 0
0x6391 3 Prefix INT8 ro - INT8 0
