7 - 8 (00292)H
Enable the Shortcut Key for Camera File Operation
Check to enable the shortcut keys relating to camera and file operations.
Main toolbar camera and file operation can be performed from the keyboard.
Move the cursor to the main toolbar operation to display a description of the status bar
operation buttons and shortcut keys.
Refer to Appendix A for details of the shortcut keys.
Turn ON the Default Settings for the fx MCFF RGB Matrix Correction
Specifies the default settings for RGB matrix correction applied when opening MDFF files
on the fx camera.
Generate the G data from Q MCFF
Check to generate Waveform Data from recorded data by G sensor of Q camera at the
following timing.
・when download MCFF file from Q camera
・when open Q camera MCFF and select “Open related Waveform file” at file menu or right
click item menu.
Then, G sensor data can be displayed in a graph.
Graph displays G data and G trigger level
The unit of a vertical axis is [G] (acceleration).
Range is 0~205.
Data channel name
G data G
G trigger level Threshold
List displays G data, G trigger level and existence of external trigger signals
Data channel name
G data G
G trigger level Threshold
Existence of external trigger signals TRIG
Measurement Function
Select the HXLink measurement function from “Measure Coordinates” and “LAA
Measurement”.
Refer to chapter 13 for the measurement function.
