13 - 22 (00292)H
13.6 LAA Operation Part
■LAA Image Playback Tool
Performs operations for image playback and frame jumping.
Play. When stopped, plays forward.
Stop. Stops playback.
1 frame forward. Moves one frame when stopped.
Rewind 1 frame. Rewinds 1 frame when stopped.
Reverse playback. Plays back in reverse when stopped.
Skip to the top frame. Displays the top frame of the file.
Go to T=0 frame. Displays the T=0 frame of the file.
Playback slider. Shows the position of the current frame. Use the mouse to jump to the
current frame on the playback slider.
Display loop playback range. Displays the set loop playback range.
Start frame:0, End frame:0 indicate the loop playback range is not set.
Example with a loop playback range set from -0.017 seconds to +0.017 seconds
Setting for loop playback start frame. The current frame becomes the loop playback
start frame.
Setting for loop playback end frame. The current frame becomes the loop playback end
frame.
Deletes the loop playback range.
