(00292)H 11 - 9
Log File Example
Items Recorded in the Log File
1. Converted Time Time after conversion (YYYYMMDDhhmmss)
2. Result Conversion results
3. BegFrame Conversion start frame
4. EndFrame Conversion end frame
5. [ConvSettingFileName] Batch conversion settings file name
6. [SrcFileName] Source file name
7. [SrcFileType] Source file type (*1)
8. [DstFileName] Destination file name
9. [DstFileType] Destination file type (*1)
10. [FcvFileName] FCV file name
*1: File Type 11： MCFF, 12： AVI, 14： BMP, 15： TIFF, 16： JPEG
■ Batch conversion maintenance
When batch converting, batch conversion settings files are saved in the completed/error
folder in the source folder and the log files are saved in the log folder.
These files are added each time batch conversion is performed and these files are deleted on
a regular basis.
11.4 Error Information
If there is a conversion error by the batch conversion software, the error information for the
conversion failure is shown in the error information column.
・List of Error Information Displayed
Error Display Error Details
100, MCFF file open error Source file does not exist, access not allowed etc.
101, RGB matrix not supported error SDC library error (due to HXLink installation failure)
102, Section data loading error Download suspended file not batch converted
103, GPU environment error Insufficient conversion processing resources (used
together with HXLink etc.)
104, MCFF file size error Download suspended file not batch converted
105, Pixel bit count error Abnormal conversion settings file, HXLink installation
failure
200, FCV file not detected error Conversion settings file does not exist, access not
allowed etc.
201, Save directory error Source folder does not exist, access not allowed etc.
202, Source image file write error Source image file in use, does not exist, access not
allowed etc.
