■Synchronize multi Q cameras with daisy-chain connection
You can synchronize Q cameras by using the first camera as standard.
You can also input external signal to the first camera.
■Synchronize multi Q cameras with Q-HUB
You can synchronize Q cameras by using Q-HUB as standard.
You can also input external signal to Q-HUB.
External input
Trigger
Ethernet
SYNC
OUT
SYNC IN
External input
SYNC IN
Ethernet
Trigger
Q-HUB
Q camera
Q camera
SYNC IN
SYNC
OUT
SYNC IN
