3 - 16 (00292)H
The playback slider bar display changes according to the recording trigger mode.
（１） Example of Event Frame Display
Handles frames where trigger signals are input from the second trigger onwards as an event
frame.
（２） Example of BURST, LINEAR Recording Display
BURST Recording Performs the time burst signals are input and recording for the
trigger input connector.
LINEAR Recording Performs recording according to the pauses in operation.
（３） Example of Multi Trigger Frame Display
Divides the memory segments into 2~64 blocks, and automatically replaces the blocks with
recording for each trigger signal input.
To Next Page
