9 Description of the object dictionary
Number
dec hex Signal source
08 08 Physical input 8
09 09 Physical input 9
10 0A Physical input 10
11 0B Physical input 11
12 0C Physical input 12
13 0D Physical input 13
14 0E Physical input 14
15 0F Physical input 15
16 10 Physical input 16
65 41 Hall input "U"
66 42 Hall input "V"
67 43 Hall input "W"
68 44 Encoder input "A"
69 45 Encoder input "B"
70 46 Encoder input "Index"
71 47 USB Power Signal
72 48 "Ethernet active" status
73 49 DIP switch 1
74 4A DIP switch 2
75 4B DIP switch 3
76 4C DIP switch 4
77 4D DIP switch 5
78 4E DIP switch 6
79 4F DIP switch 7
80 50 DIP switch 8
128 80 Signal is always 1
129 81 Inverted physical input 1
130 82 Inverted physical input 2
131 83 Inverted physical input 3
132 84 Inverted physical input 4
133 85 Inverted physical input 5
134 86 Inverted physical input 6
135 87 Inverted physical input 7
136 88 Inverted physical input 8
137 89 Inverted physical input 9
138 8A Inverted physical input 10
139 8B Inverted physical input 11
140 8C Inverted physical input 12
141 8D Inverted physical input 13
142 8E Inverted physical input 14
143 8F Inverted physical input 15
144 90 Inverted physical input 16
193 C1 Inverted Hall input "U"
194 C2 Inverted Hall input "V"
195 C3 Inverted Hall input "W"
Version: 2.0.1 / FIR-v1650 184
