Nordson Asymtek M-2000 User Manual

Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 2-2-22 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-4-2
Dispensing Head Performs a Height Sense
FmNT Command
y A program command is issued to the
FmNT software
PMAC Card
y Sends command to lower the dispensing
head to the Servo Interconnect PCA.
Servo Interconnect PCA
y Relays command to lower the dispensing
head to the Z-axis Servo Control
Amplifier.
Z-axis Servo Control Amplifier
y Activates the Z-axis Servo Motor.
Z-axis Servo Motor
y Activates to lower the dispensing head.
Height Sensor Probe Input
y When the Height Sensor Probe touches
the substrate, a Height Sense Touch
input occurs which the Height Sensor
relays to the Interconnect PCA.
Interconnect PCA
y Relays the Height Sense Touch input to
the Interface PCA.
Interface PCA
y Sends a Position Capture output to the
Interconnect PCA.
y Relays Height Sense Touch input to the
PIO-96-J Card.
Interconnect PCA
y Relays Position Capture output
from Interface PCA to the Servo
Interconnect PCA.
PIO-96-J Card
y Receives Height Sense Touch input from
Interface PCA. Responds with a PMAC
Stop output to the Interface PCA.
Interface PCA
y Relays PMAC Stop output from the PIO-
96-J Card to the PMAC Card.
PMAC Card
y Relays PMAC Stop output to the
Servo Interconnect PCA.
Servo Interconnect PCA
y Relays PMAC Stop output to the Z-
axis Servo Control Amplifier.
Z-axis Servo Control Amplifier
y Receives PMAC Stop output from
the Servo Interconnect PCA and
stops Z-axis Servo Motor.
Z-axis Servo Motor Stops
Servo Interconnect PCA
y Receives Position Capture output
from Interconnect PCA. Outputs
current X, Y and Z-axis position
information to the PMAC Card.
PMAC Card
y Relays X, Y and Z-axis position
information to the software.
