Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 2-2-24 P/N 73-0018-00 (Revision B)
Diagram Sheet 2-4-4
Conveyor Belt Movement
FmNT Command
y
A program command is issued to
the FmNT software
COM1 on Computer System
y
Com Port through which the
computer communicates with the
Conveyor Controller Module.
Conveyor Controller Module
y
Supplies power to the stepper
motors.
y
Communicates with the system
computer to coordinate conveyor
operation.
COM2 on Computer System
y
If your system is equipped with a
dual-lane conveyor, the system will
have two Conveyor Controller
Modules. The second Conveyor
Controller Module communicates
with the computer through Com 2.
Conveyor Controller Module (2)
y
Supplies power to the stepper
motors.
y
Communicates with the system
computer to coordinate conveyor
operation.
Stepper Motor
y
Activates to turn the Conveyor Belt
Driver Wheel.
Stepper Motor
y
Activates to turn the Conveyor Belt
Driver Wheel.
Conveyor Belt Driver Wheel
y
Located on the conveyor.
y
Belt wraps around Driver Wheel.
When Driver Wheel turns, belt
moves.
Conveyor Belt Driver Wheel
y
Located on the conveyor.
y
Belt wraps around Driver Wheel.
When Driver Wheel turns, belt
moves.
Optional Configuration for Dual Lane Conveyor
RS232 Conveyor Cable RS232 Conveyor Cable
Belt Motor Cable Belt Motor Cable
To Next Page
