Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 2-2-35 P/N 73-0018-00 (Revision B)
Information Sheet 2-6-2
DP-3000 Series
A. Description
1. The DP-3000 is a servo-controlled, piston type pump.
2. It is capable of dispensing a specified amount of fluid at relatively high flow rates.
3. It is also capable of accurate volume repeatability, regardless of fluid viscosity.
B. Operation
1. Fluidmove commands signal the pneumatic module to supply air pressure to the
actuator, forcing the stopcock to open and close.
2. The DP-3000 dispenses material at a rate dependent upon the motor speed setting,
the model, and the gear configuration.
3. The piston is motor-driven, advancing at a controlled, constant volumetric rate.
4. The amount of fluid dispensed is controlled by setting the valve-on time within the
Fluidmove software.
C. Features
1. Two part, detachable pumping/priming chamber.
2. Upper knob manual determination of piston location and control.
3. Unique design of wire and electronic casing.
4. Lightweight material construction.
5. Pump finish resists adhesion of fluids.
6. Easier installation and handling.
7. Airtight sealed pumping chamber and assembly.
8. High level of accuracy.
D. Adjustments
1. There are several hardware and software adjustments you can make to optimize
performance.
2. These include:
 Priming the Needle
 Automatic Refill
 Needle Heater
 Various Needle Sizes
