Precautions for Correct Use
When you perform absolute positioning, set the target position so that the settings of the
Modulo Maximum Position Setting V
alue and Modulo Minimum Position Setting Value ax-
is parameters are not exceeded.
If the target position is set outside of the settings of the Modulo Maximum Position Setting
Value and Modulo Minimum Position Setting Value axis parameters, a Target Position Set-
ting Out of Range error (error code 5478 hex) will occur.

In-position Check
An in-position check is performed for this instruction according to the settings in In-position Range
and In-position Check T
ime axis parameters.
Re-execution of Motion Control Instructions
You can change the operation of the instruction if you change an input variable during positioning and
change Execute to TRUE again.
Input variables Position (T
arget Position), Velocity (Target Velocity), Acceleration (Acceleration Rate),
and Deceleration (Deceleration Rate) can be changed by re-executing the motion control instruction.
For details on re-execution of motion control instructions, refer to the NY-series Industrial Panel PC /
Industrial Box PC Motion Control User’s Manual (Cat. No. W559).
Multi-execution of Motion Control Instructions
For details on multi-execution of motion control instructions, refer to the NY
-series Industrial Panel
PC / Industrial Box PC Motion Control User’s Manual (Cat. No. W559).

Execution during Execution of Other Instructions
You can switch to this instruction or buffer this instruction if you execute it during execution of another
instruction.
You can buffer one instruction per axis.
Specify the operation of this instruction with BufferMode (Buffer Mode Selection) for multi-execution of
instructions.
Buffer Mode Selec-
tion
Description
Aborting Aborts the instruction being executed and switches to this instruction.
If the direction of axis motion is reversed by switching instructions, the motion will be
reversed according to the Operation Selection at Reversing
axis parameter.
Buffered Buffers this instruction and executes it automatically after the current instruction is com-
pleted.
Blending Starts the buffered instruction at the velocity (transit velocity) at which the current in-
struction reaches the target position. The operation of the current instruction is changed
so that the axes reach the target position at the transit velocity
. There are four methods
to specify the transit velocity. These are described below.
3 Axis Command Instructions
3-51
NY-series Motion Control Instructions Reference Manual (W561)
MC_Move
3
Function
