Input Variables
Name Meaning Data type Valid range
De-
fault
Description
Execute Execute BOOL TRUE or FALSE FALS
E
The instruction is executed when the
value of this variable changes to
TRUE.
Other input variables are also input
when Execute changes to TRUE.
If input values are changed, they will
be updated when Execute changes
to TRUE again.
The output variables are valid as
long as Execute remains TRUE
even after the instruction is complet-
ed.
Then, all output variables except for
Error and ErrorID are disabled when
Execute changes to F
ALSE.
If Execute changes to FALSE before
the instruction is completed, output
variables are valid for at least one
period.
Enable Enable BOOL TRUE or FALSE FALS
E
The instruction function is enabled
when the value of this variable
changes to TRUE and disabled
when it changes to F
ALSE.
While Enable is TRUE, the other in-
put variables are input every period.
If Enable changes to FALSE, all out-
put variables except for Error and
ErrorID are disabled.
PositiveEna-
ble
Positive Di-
rection Enable
BOOL TRUE or FALSE FALS
E
• MC_MoveJog Instruction
When this variable changes to
TRUE, the axis starts moving in
the positive direction. When it
changes to FALSE, the axis stops
moving. The Velocity,
Acceleration, and Deceleration in-
put variables to the MC_MoveJog
instruction are read when
PositiveEnable changes to TRUE.
• MC_SetTorqueLimit Instruction
When this variable changes to
TRUE, the positive torque limit is
enabled. When it changes to
FALSE, the positive torque limit is
disabled.
2 Variables and Instructions
2-13
NY-series Motion Control Instructions Reference Manual (W561)
2-1 Variables
2
2-1-4 Input Variables for Motion Control Instructions
