Parker AC30 series User Manual

Parameter Reference C-9
AC30 series Variable Speed Drive
Line Synchronisation
Typically the system will contain an AC30P/AC30D regen drive providing 4-Q power supply, and one or more drives on the common DC bus.
However, in order for the AFE control procedures to operate correctly, a synchronization of the IGBT firing sequence to the three phase mains
supply voltage frequency, angle, and direction of rotation need to be performed. This is achieved by using a line sync card (LA471892U001),
connected to a standard AC30 encoder option board (7004-04-00). Failure to successfully synchronise could cause significant supply distortion, poor
power factor, or even catastrophic failure.
AFE Parameter List
The full set of AFE related parameters are given in a table below:
Parameter Name
No.
Path
Default
Range
Units
Writable
AFE Inductance
1730 Setup::Regen Control
Parameters
::Regen Control::AFE
0.00 0.00 to 1000.00 mH ALWAYS
Total inductance (3% + 5%) from the LCL filter in the AFE configuration.
AFE PF Angle Demand
1693 Parameters::Regen Control::AFE 0.00 -90.00 to 90.00 deg ALWAYS
Sets AFE in current control mode (TRUE) or leaves it in voltage control mode (FALSE).
AFE Id Demand
1705 Same as PNO 1693 0.10 -1.50 to 1.50 ALWAYS
Iq current demand. Set directly in both current control mode, or voltage control mode.
AFE Id Demand
1704
Same as PNO 1693 0.10 -1.50 to 1.50
ALWAYS
Id current demand. Set directly only in current control mode. In voltage control mode set by dc link voltage loop.
AFE Max Current
1706
Parameters::Regen Control::AFE 1.50 0.00 to 1.50
ALWAYS
Maximum allowed current in AFE mode.
AFE Close Ext PCR
1690 Parameters::Regen Control::AFE FALSE ALWAYS

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
