Parker AC30 series User Manual

C-12 Parameter Reference
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Drive enabled to do AFE.
AFE PF Angle Demand
1692 Parameters::Regen Control::AFE 0.00 -90.00 to 90.00 deg ALWAYS
Power factor angle demand.
AFE Phase Loss
1715 Parameters::Regen Control::AFE NEVER
Indicates if phase loss occurred.
AFE Brake Mode
1716 Parameters::Regen Control::AFE FALSE ALWAYS
Sets AFE control into brake mode.
AFE Status
1721 Same as PNO 1703 0:INACTIVE
1:SYNCHRONIZING
2:SYCHRONIZED
3:SUPPLY FREQ HIGH
4:SUPPLY FREQ LOW
5:SYNC FAILED
NEVER
AFE module status reporting.
NOTES
1 – To correctly set up AFE mode for frame K
- phase fail trip needs to be disable in AFE mode
- parameter 1707 needs to be set at 0.75
- parameter 1708 needs to be set at 0.02

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
