Parker AC30 series User Manual

Parameter Reference C-59
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Nominal Supply
0976
Parameters::Device Manager::Drive info
0
0:50 Hz
1:60 Hz
ALWAYS
Defines the default supply frequency. In the GKP Setup Wizard, this parameter controls the default values for this child parameters:
PNO Parameter 50Hz 60Hz
0464 100% Speed in RPM 1500 1800
0456 Base Voltage 400 460
0457 Base Frequency 50 60
0459 Nameplate Speed 1450 1750
When this parameter is changed from the GKP or Web page when PNO1869 “Auto Defaults” is TRUE then the child parameters are
set to their corresponding default values, (and saved if PNO1738 “Enable Auto Save” is TRUE).
Power Stack Required
0987
Parameters::Device Manager::Drive info
0 Same as PNO 543
CONFIG
The rating of the power electronics for the configuration loaded in the drive. This controls the default value for the child parameters
listed in the Power Dependent Parameter Defaults table at the end of this appendix.
If 0987 Power Stack Required is different from 0543 Power Stack Fitted the drive will be prevented from running until the configuration
is corrected.
If Power Stack Required is set to NONE, then it is automatically reset to match Power Stack Fitted on the next power on. This does not
automatically modify any of the child parameters. To do this, set PNO 1869 Auto Defaults to TRUE.
Power Stack Fitted
0543
Parameters::Device Manager::Drive info
0:NONE
1:3.5 A 400 V
2:4.5 A 400 V
3:5.5 A 400 V
4:7.5 A 400 V
5:10.0 A 400 V
6:12.0 A 400 V
7:16.0 A 400 V
8:23.0 A 400 V
9:32.0 A 400 V
10:38.0 A 400 V
11:45.0 A 400 V R1
12:60.0 A 400 V R1
13:73.0 A 400 V R1
NEVER

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
