Parker AC30 series User Manual

C-70 Parameter Reference
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Actual Speed rps
0394
Same as PNO 393
x.xx -1500.00 to 1500.00 rev/s
NEVER
This parameter changes according to the Control Strategy:
• In Vector Control mode the parameter shows the calculated mechanical speed of the motor shaft in revolutions per second.
• In Volts-Hertz Control mode, the parameter shows the motor synchronous speed in revolutions per second.
Actual Speed Percent
0395
Same as PNO 393
x.xx -200.00 to 200.00 %
NEVER
This parameter changes according to the Control Strategy
• In Vector Control mode the parameter shows the calculated mechanical speed of the motor shaft as a percentage of the user
maximum speed setting (100% Speed in RPM in the Scale Setpoint function).
• In Volts-Hertz Control mode, the parameter shows the electrical drive output frequency as a percentage of the user maximum
speed setting (100% Speed in RPM in the Scale Setpoint function).
DC Link Volt Filtered
0396
Same as PNO 393
x. 0 to 1000 V
NEVER
This shows the filtered voltage across the dc link capacitors.
DC Link Volts Trim
0119
Parameters::Motor Control::Feedbacks
0 -20 to 20 V ALWAYS
Specifies a trim to add to the DC Link voltage feedback. This is useful when it is necessary for all the drives in a system to read exactly
the same DC Link voltage.
id
0397
Parameters::Motor Control::Feedbacks
x.x -600.0 to 600.0 %
NEVER
Current in the flux axis (Vector Control)
iq
0398
Parameters::Motor Control::Feedbacks
x.x -600.0 to 600.0 %
NEVER
Current in the torque axis (Vector Control)
