Parker AC30 series User Manual

Menu Organisation 5-4
AC30 series Variable Speed Inverter
AFE Iq Demand
1705
AFE Id Demand
1704
Inputs and Outputs
Base IO
Anin 01 Type
0001
Anin 01 Offset
0957
Anin 01 Scale
0958
Anin 02 Type
0002
Anin 02 Offset
0959
Anin 02 Scale
0960
Anout 01 Type
0003
Anout 01 Scale
0686
Anout 01 Offset
1108
Anout 01 ABS
1441
Anout 02 Type
0004
Anout 02 Scale
1460
Anout 02 Offset
1467
Anout 02 ABS
1468
Option
Option IO Required
1178
Thermistor Type
1184
Encoder Supply
1511
Encoder Lines
1512
Encoder Invert
1513
Encoder Type
1514
Encoder Single Ended
1515
Encoder Count Reset
1517
Resolver Frequency
1791
Resolver Voltage
1790
Resolver Ratio
1792
Resolver Max Speed
1825
Resolver Poles
1793
Resolver Built-In Gear
1822
Resolver Invert
1810
Resolver Speed Filter
1815
Resolver Min Filter
1851
Resolver Resolution
1816
Anin 11 Offset
1461
Anin 11 Scale
1462
Anin 12 Offset
1463
Anin 12 Scale
1464
Anin 13 Offset
1465
Anin 13 Scale
1466
System Board Option
System Board Required
1739
Output Enable
1678
Output Source
1679
Output Voltage
1680
Output A
1756
Output B
1757
Output Z
1758
Synth Encoder Lines
1696
Synth Encoder Speed
1698
Synth Encoder Invert
1702
SB Encoder Slot1
Encoder Supply
1663
Encoder Lines
1664
Encoder Invert
1665
Encoder Type
1666
High Input Threshold
1667
Encoder Count Reset
1669
SB Encoder Slot2
Encoder Lines
1671
Encoder Invert
1672
Encoder Type
1673
High Input Threshold
1674
Encoder Count Reset
1676
Communications
Base Ethernet
DHCP
0929
Auto IP
0930
User IP Address
0933
User Subnet Mask
0934
User Gateway Address
0935
Web Access
0944
Base Modbus
Maximum Connections
0939
High Word First
0940
Modbus Timeout
0941
Modbus Trip Enable
0942
Modbus Mapping[16]
1567
Modbus TCP Password
1659
Base Ethernet IP
Ethernet IP Enable
3128
Ethernet IP Trip
3129
Input Mapping
3000
Output Mapping
3064
Option
Comms Required
0044
BACnet MAC Address
1091
BACnet MSTP Device ID
1092
BACnet Baud Rate
1093
BACnet MSTP Timeout
1094
BACnet IP Device ID
0209
BACnet IP Timeout
0210
CANopen Node Address
0212
