Parker AC30 series User Manual

Menu Organisation 5-5
AC30 series Variable Speed Inverter
CANopen Baud Rate
0213
ControlNet MAC ID
0215
DeviceNet MAC ID
0219
DeviceNet Baud Rate
0220
Modbus Device Address
0229
Modbus RTU Baud Rate
0230
Parity And Stop Bits
0231
High Word First RTU
0232
Modbus RTU Timeout
0233
High Word First TCP
0235
Profibus Node Address
0238
Modbus TCP Timeout
0236
Address Assignment
0199
Fixed IP Address
0200
Fixed Subnet Mask
0201
Fixed Gateway Address
0202
Option Web Enable
0203
Web Parameters Enable
0204
Option FTP Enable
0205
Option FTP Admin Mode
0206
IPConfig Enable
0207
Comms Trip Enable
0048
Comms Reset Allow
1853
BACnet Max Master
1095
BACnet Max Info Frames
1096
DNet Producing Inst
0222
DNet Consuming Inst
0223
CNet Producing Inst
0216
CNet Consuming Inst
0217
ENet Producing Inst
0226
ENet Consuming Inst
0227
Modbus Password
1640
Read Mapping[32]
0055
Write Mapping[32]
0120
PTP
PTP Enable
1661
PTP Clock Type
1684
PTP Clock Mode
1683
PTP Domain Number
1787
PTP Log Sync Interval
1681
PTP Priority2
1686
PTP Lock Threshold
1685
Peer to Peer
Peer to Peer Enable
1725
Destination IP Address
1726
Destination Port
1727
Local Port
1728
Clone
Clone Filename
1534
Clone Direction
1537
Full Restore
1538
Application
1539
Power Parameters
1541
Other Parameters
1540
Clone Start
1542
Clone Status
1543
Environment
Drive Name
0961
GKP Password
1142
Web Access
0944
Display Timeout
0983
Startup Page
0982
Monitor
Quick Monitor
Application
Motor and Drive
Actual Speed RPM
0393
DC Link Voltage
0392
Actual Speed rps
0394
Actual Speed Percent
0395
DC Link Volt Filtered
0396
Actual Torque
0399
Actual Field Current
0400
Motor Current Percent
0401
Motor Current
0402
Motor Terminal Volts
0405
Actual Pos Torque Lim
0420
Actual Neg Torque Lim
0421
Heatsink Temperature
0407
CM Temperature
0406
PMAC Wiring
1809
Inputs and Outputs
Digout Value
0022
Digin Value
0005
Anout 01 Value
0042
Anout 02 Value
0043
Anin 01 Value
0039
Anin 01 Break
0040
Anin 02 Value
0041
Anin 11 Value
1181
Anin 12 Value
1182
Anin 13 Value
1183
Encoder Speed
1516
Encoder Count
1518
SB Digital Input 1
1759
SB Digital Input 2
1722

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
