Parker AC30 series User Manual

Menu Organisation 5-6
AC30 series Variable Speed Inverter
SB Digital Input 3
1723
Resolver Speed %
1814
resolver position
1824
Resolver Turns
1811
Resolver Fraction Turns
1812
System Board
Encoder Slot 1
Encoder Speed
1668
Encoder Count
1670
Encoder Slot 1
Encoder Speed
1675
Encoder Count
1677
Communications
Base Ethernet
Ethernet State
0919
MAC Address
0920
IP Address
0926
Subnet Mask
0927
Gateway Address
0928
Base Modbus
Open Connections
1241
Process Active
0943
Mapping Valid
1632
Base Ethernet IP
Ethernet IP State
3130
Ethernet IP Diag
3131
Option
Comms Fitted
0045
BACnet MSTP State
1089
BACnet IP State
0208
Profibus State
0237
EtherNet IP State
0225
Modbus TCP State
0234
Modbus RTU State
0228
EtherCAT State
0224
PROFINET State
0239
PROFINET Device Name
0240
CANopen State
0211
ControlNet State
0214
DeviceNet State
0218
CANopen Actual Baud
1251
DeviceNet Actual Baud
0221
Comms Supervised
0047
Comms Event Active
0186
Option MAC Address
0189
Option IP Address
0195
Option Subnet Mask
0196
Option Gateway
0197
Option DHCP Enabled
0198
Comms Module Version
0049
Comms Module Serial
0050
Comms Diagnostic
0051
Comms Diagnostic Code
0052
Comms Exception
0053
Comms Net Exception
0054
PTP
PTP State
1689
PTP Clock
1699
PTP Offset
1687
PTP Locked
1688
Peer to Peer
Peer to Peer State
1729
Energy Meter
Energy kWh
0383
Power kW
0380
Power HP
0381
Reactive Power
0382
Power Factor Est
0385
Trips
First Trip
0696
Active 1 - 32
0763
Active 33 - 64
0513
Warnings 1 - 32
0829
Warnings 33 - 64
0514
RTA Code
0998
RTA Data
0999
Regen Control
AFE Sync Frequency
1703
AFE Status
1721
DC Link Voltage
0392
Favourites

Parker AC30 series Specifications

General

Control Modes	Closed-loop vector
Feedback	Encoder
Operating Temperature	0 to 40°C (32 to 104°F) standard, -20 to 50°C (-4 to 122°F) with derating
Protection	Overcurrent, Overvoltage, Undervoltage
Communication	RS485
