Parker AC30 series User Manual

C-184 Parameter Reference
AC30 series Variable Speed Drive
Parameter Name
No.
Path
Default
Range
Units
Writable
Synth Encoder Invert
1702
Same as PNO 1678 FALSE ALWAYS
Sets the direction of the synthetic encoder rotation.
Z Pulse
1870
Setup::Inputs and Outputs::System Board
Option
Parameters::System Board::SB
Retransmit
FALSE ALWAYS
Only available is Output Source is set to SYNTHETIC ENCDR or MAIN SPD FEEDBACK
Allows to set up the Z pulse signals. It occurs on the falling edge ( TRUE to FALSE ) of this parameter.
Z Pulse Init Done
1872
Setup::Inputs and Outputs::System Board
Option
Parameters::System Board::SB
Retransmit
FALSE ALWAYS
Only available is Output Source is set to MAIN SPD FEEDBACK
TRUE if initialisation of Z pulse position has been run successfully. FALSE during initialisation phase : at start up or during selection of
a new Z pulse position.
Output A
1756
Setup::Inputs and Outputs::System Board
Option
Parameters::System Board::SB
Retransmit
FALSE ALWAYS
Value presented on terminal X33.1 with respect to X33.2 when "1679 Output Source" is set to DIGITAL OUTPUTS
Output B
1757
Same as PNO 1756 FALSE ALWAYS
Value presented on terminal X33.3 with respect to X33.4 when "1679 Output Source" is set to DIGITAL OUTPUTS
Output Z
1758
Same as PNO 1756 FALSE ALWAYS
Value presented on terminal X33.5 with respect to X33.6 when "1679 Output Source" is set to DIGITAL OUTPUTS
