Parker AC30 series User Manual

Parameter Reference C-265
AC30 series Variable Speed Drive
3029
Input Mapping[28]
Same as PNO 3000
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06585
3030
Input Mapping[29]
Same as PNO 3000
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06587
3031
Input Mapping[30]
Same as PNO 3000
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06589
3032
Input Mapping[31]
Same as PNO 3000
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06591
3064
Output Mapping
Setup::Communications::Base PROFINET
Parameters::Base Comms::Fieldbus Mapping
ARRAY[0..31]
CONFIG
ENGINEER
06655
3065
Output Mapping[0]
Same as PNO 3064
UINT
0661
0000 to 3145
CONFIG
ENGINEER
06657
3066
Output Mapping[1]
Same as PNO 3064
UINT
0395
0000 to 3145
CONFIG
ENGINEER
06659
3067
Output Mapping[2]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06661
3068
Output Mapping[3]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06663
3069
Output Mapping[4]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06665
3070
Output Mapping[5]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06667
3071
Output Mapping[6]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06669
3072
Output Mapping[7]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06671
3073
Output Mapping[8]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06673
3074
Output Mapping[9]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06675
3075
Output Mapping[10]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06677
3076
Output Mapping[11]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06679
3077
Output Mapping[12]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06681
3078
Output Mapping[13]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06683
3079
Output Mapping[14]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06685
3080
Output Mapping[15]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06687
3081
Output Mapping[16]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06689
3082
Output Mapping[17]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06691
3083
Output Mapping[18]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06693
3084
Output Mapping[19]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06695
3085
Output Mapping[20]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06697
3086
Output Mapping[21]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06699
3087
Output Mapping[22]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06701
3088
Output Mapping[23]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06703
3089
Output Mapping[24]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06705
3090
Output Mapping[25]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06707
3091
Output Mapping[26]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06709
3092
Output Mapping[27]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06711
3093
Output Mapping[28]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06713
3094
Output Mapping[29]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06715
3095
Output Mapping[30]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06717
3096
Output Mapping[31]
Same as PNO 3064
UINT
0000
0000 to 3145
CONFIG
ENGINEER
06719
3132
PROFINET Enable
Setup::Communications::Base PROFINET
Parameters::Base Comms::PROFINET IO Device
BOOL
FALSE
CONFIG
TECHNICIAN
06791
3133
PROFINET Trip
Same as PNO 3132
USINT
(enum)
1
0:DISABLED
1:ENABLED
CONFIG
ENGINEER
06793
3134
PROFINET Use Drive IP
Same as PNO 3132
BOOL
FALSE
CONFIG
ENGINEER
06795
3135
PROFINET Acyclic Endn
Same as PNO 3132
USINT
(enum)
1
0:LITTLE ENDIAN
1:BIG ENDIAN
ALWAYS
ENGINEER
06797
3136
PROFINET Station Name
Monitor::Communications::Base PROFINET
Parameters::Base Comms::PROFINET IO Device
STRING[21]
NEVER
OPERATOR
06799
3143
PROFINET State
Same as PNO 3136
USINT
(enum)
Same as PNO 239
NEVER
OPERATOR
06813
3144
PROFINET Diagnostic
Same as PNO 3136
USINT
(enum)
0:NONE
1:INPUT MAPPING FAILED
2:OUTPUT MAPPING FAILED
3:CONNECTION REJECTED
4:MAPPING MISMATCH
NEVER
OPERATOR
06815
