VNA GUI reference

R&S

ZNL/ZNLE

560User Manual 1178.5966.02 ─ 20

Overview

See "Overview" on page 543.

Type

Currently only Differential Match"Embedding" is supported.

Logical Port

Logical analyzer port, as defined in the "Balanced Ports" configuration. The transfor-

mation networks are defined such that the physical analyzer test ports are connected

to the left of the circuit; the DUT ports are on the right side. You can define independ-

ent embedding networks for all balanced ports.

Remote command:

The <LogPt> numeric suffix in the embedding/deembedding commands identifies the

logical port; see e.g. CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:

EMBedding<LogPt>[:STATe].

Network

The graphical list contains the available 2-port networks for Differential Match embed-

ding:

●

The

symbol selects "no network" and disables differential match embedding for

the selected balanced port.

●

The "2-Port Data" network is defined by means of imported S-parameter data; see

Select File...

●

The "Shunt L, Shunt C" network is defined by lumped elements whose parameters

are displayed below the graphical list.

Tip: Drag and drop the network symbols in horizontal or vertical direction to switch to

the next symbol.

Remote command:
