Parameters:
<Boolean> ON – channel bits 4 to 7
OFF – drive port 1 to 4
*RST: ON
Example: See OUTPut<Ch>:UPORt[:VALue]
Manual operation: See "Pin 16 - 19" on page 532
OUTPut:UPORt:KEEP <Boolean>
Defines the behavior of the channel bits at sweep end.
Parameters:
<Boolean> ON (1)
Channel bits keep their state.
OFF (0)
Channel bits are reset.
*RST: OFF
OUTPut<Ch>:UPORt:SEGMent<Seg>:STATe <Boolean>
Enables or disables segment bits for the sweep segments in channel no. <Ch>; see
OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue]. The command is valid for segmen-
ted frequency sweep.
Suffix:
<Ch>
.
Channel number.
<Seg> Sweep segment number. This suffix is ignored; the setting is
valid for all segments.
Parameters:
<Boolean> ON | OFF - Enables or disables channel bits.
*RST: OFF
Example: See OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue]
on page 873
Manual operation: See "Optional Columns" on page 337
OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue] <BinValue>
Sets or queries a sweep segment-dependent four-bit binary value to control four inde-
pendent output signals at the USER PORT connector (lines 16, 17, 18, 19). The output
signals are 3.3 V TTL signals which can be used to differentiate between up to 16 inde-
pendent analyzer states for each channel. The command is valid for segmented fre-
quency sweeps. It is analogous to the channel-dependent command
OUTPut<Ch>:UPORt[:VALue].
The bits for the sweep segments must be enabled explicitly using
OUTPut<Ch>:UPORt:SEGMent:STATe.
