R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
890User Manual 1178.5966.02 ─ 20
Calibration kit names must be entered as string parameters. The string contains the cal
kit name used in the calibration dialogs (e.g. "Calibration Presettings"); a "Ω" in the
name must be replaced by Ohm, e.g.:
●
NewKit1 denotes the user-defined calibration kit "NewKit1".
●
N 50 Ohm Ideal Kit denotes the "N 50 Ω Ideal Kit".
●
ZV-Z21 typical denotes the cal kit "ZV-Z21 typical".
Suffix:
<ConnType>
.
Connector type, one of the following identifiers:
N50, N75 – N 50 Ω or N 75 Ω connectors
PC7, PC35, PC292 – PC 7, PC 3.5 or 2.92 mm connectors
USER<no> – user-defined connectors UserConn1, UserConn2
SMA – user-defined connector type SMA ...
Parameters:
<CalKitName> String parameter containing the name of a calibration kit availa-
ble on the analyzer. See "Cal kit naming conventions " above.
*RST: n/a (A *RST does not change the assignment
between connector types and calibration kits.)
Example:
MMEM:LOAD:CKIT 'C:\Users\Public\
Documents\Rohde-Schwarz\ZNL\
Calibration\Kits\New Kit 1.calkit'
Load the previously created cal kit file New Kit 1.calkit
from the default cal kit directory.
CORR:CKIT:N50:SEL 'New Kit 1'
Assign the imported kit to the N 50 Ω connector type, assuming
that the cal kit name stored in New Kit 1.calkit reads New
Kit 1.
Manual operation: See "Add / Copy / Delete / Standards..." on page 500
[SENSe:]CORRection:CKIT:STANdard:CATalog? <CalKitName>
Returns a list of all standards in a given calibration kit.
Query parameters:
<CalKitName> Name of the cal kit. Use [SENSe:]CORRection:CKIT:
CATalog? to query cal kit names.
Example: See [SENSe<Ch>:]CORRection:CONNection:CATalog?
Usage: Query only
[SENSe:]CORRection:CKIT:STANdard:DATA? <ConnectorType>, <CalKitName>,
<KitLabel>, <StandardType>, <DelayMode>[, <Port1>[, <Port2>]]
Returns the data of the related calibration standard (identified by <ConnectorType>,
<CalKitName>, <KitLabel> and <StandardType>) and - optionally - restricted to the
given port(s).
