R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
895User Manual 1178.5966.02 ─ 20
Manual operation: See "Add / Copy / Delete / Standards..." on page 500
[SENSe:]CORRection:CKIT:STANdard:LCATalog? <CalKitName>, <KitLabel>
Returns a list of all standards in a given calibration kit.
Query parameters:
<CalKitName> Name of the cal kit. Use [SENSe:]CORRection:CKIT:
LCATalog? to query cal kit names and labels.
<KitLabel> Label of the cal kit.
Example: See [SENSe<Ch>:]CORRection:CONNection:CATalog?
Usage: Query only
[SENSe:]CORRection:CKIT:<StandardType>:WLABel
<ConnType>, <CalKitName>,
<CalKitLabel>, <StandardLabel>, <MinFreq>, <MaxFreq>, <DelayParam>,
<Loss>, <Z0>, <C0>, <C1>, <C2>, <C3>, <L0>, <L1>, <L2>, <L3>, OPEN |
SHORt | MATCh | <Resistance>[, <Port1>[, <Port2>]]
[SENSe:]CORRection:CKIT:<StandardType>:WLABel? <ConnType>[,
<CalKitName>[, <CalKitLabel>[, <Port1>[, <Port2>]]]]
Defines the parameters of a non-ideal 1 port or 2-port calibration standard
<StandardType>, where a particular cal kit can be addressed by name and label.
Apart from the additional <CalKitLabel> parameter, the syntax and semantics of this
command is identical to Standard types and their parameters.
Example:
CORR:CKIT:FOP:WLAB 'N 50 Ohm','New Kit
1','123456', '',
0,4000000000,0,0,50,99,-2.3,0.22,0,0,0,0,0
Define the properties of the Open (f) standard for a N 50 Ω con-
nector type in the calibration kit "New Kit 1" labelled "123456".
CORR:CKIT:FOP:WLAB? 'N 50 Ohm', 'New Kit 1',
'123456'
Query the properties of the Open (f) standard for a N 50 Ω con-
nector type in the calibration kit.
Manual operation: See "Add / Copy... / Delete / View / Modify..." on page 502
[SENSe:]CORRection:CKIT:<OnePortStandardType>:WLABel:SDATa?
<ConnectorType>, <CalKitName>[, <CalKitLabel>[, <PhysPort>]]
Reads the S-parameter data for a particular 1-port cal kit standard previously loaded
from Touchstone file using MMEMory:LOAD:CKIT:SDATa or MMEMory:LOAD:CKIT:
SDATa:WLABel.
The cal kit is identified by its name and label.
