R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
914User Manual 1178.5966.02 ─ 20
[SENSe<Ch>:]CORRection:COLLect:CONNection:PORTs <ConnectorType>
Qualifies whether the connector types at the test ports (but not their gender) are equal
or independent. Some calibration types require uniform port connector types.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Parameters:
<ConnectorType> ALL | SINGle
ALL – equal (uniform) connector types. If the connector type at
one port is changed, the connector type at all other ports is
changed accordingly.
SINGle – independent (possibly non-uniform) connector types at
the ports.
*RST: ALL
Example:
CORR:COLL:CONN:PORTS SING
Select independent connector types at the ports.
CORR:COLL:CONN1 N50MALE; CONN4 N75FEMALE;
CONN2?
Select independent connector types at ports 1 and 4. The con-
nector type at port 2 is not changed; the query returns
N50FEMALE.
Manual operation: See "Same Connector All Ports / Same Gender All Ports"
on page 485
[SENSe<Ch>:]CORRection:COLLect:DELete [<CalName>]
Deletes system error correction data generated and stored previously.
Suffix:
<Ch>
.
Channel number of the calibrated channel
Setting parameters:
<CalName> Name of the calibration (string parameter) defined together with
the calibration type ([SENSe<Ch>:]CORRection:COLLect:
METHod:DEFine).
ALL - the analyzer deletes all calibrations.
If nothing is specified the analyzer deletes the last system error
correction stored by means of [SENSe<Ch>:]CORRection:
COLLect:SAVE:SELected[:DUMMy].
*RST: -
VNA command reference
