R&S ZNL Series User Manual

Command reference
R&S
®
ZNL/ZNLE
949User Manual 1178.5966.02 ─ 20
[SENSe:]POWer...
The [SENSe:]POWer... commands configure the optional receiver step attenuators
(see Chapter 9.7.6, "Receiver step attenuators", on page 303).
[SENSe<Ch>:]POWer:ATTenuation..................................................................................949
[SENSe<Ch>:]POWer:ATTenuation <arg0>[, <arg1>]
Sets an attenuation factor for the received waves. This command is available if at least
one of the Receiver step attenuators is installed.
Suffix:
<Ch>
.
Channel number
Parameters:
<arg0> Physical port number
Instead of port numbers 1 and 2 you can also use the constants
ARECeiver and BRECeiver, respectively.
Default unit: n/a
<arg1> Attenuation factor for the received wave.
Range: 0 dB, 10 dB, 20 dB, 30 dB. The analyzer rounds
any entered value below the maximum attenuation
to the closest step.
*RST: 0 dB
Default unit: dB
Example:
POW:ATT AREC, 10
Set an attenuation factor of 10 dB for the waves received at test
port 1 and channel no. 1. The other test ports and channels are
not affected.
Manual operation: See "Step Attenuators" on page 313
[SENSe:]SEGMent...
The [SENSe:]SEGMent<Seg>... commands define all channel settings for a seg-
mented frequency sweep. A segmented sweep is activated via [SENSe<Ch>:
]SWEep:TYPE SEGMent.
The commands in this subsystem do not accept the step parameters UP and DOWN.
Numeric values can be entered directly or using the DEFault, MINimum, MAXimum
parameters.
[SENSe<Ch>:]SEGMent<Seg>:ADD................................................................................950
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]........................................................ 950
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:CONTrol...........................................951
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:SELect............................................. 952
[SENSe<Ch>:]SEGMent<Seg>:BWIDth[:RESolution]:SELect:CONTrol................................952
[SENSe<Ch>:]SEGMent:COUNt?....................................................................................953
[SENSe<Ch>:]SEGMent<Seg>:DEFine............................................................................954
VNA command reference
