R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 993
SOURce<Ch>:POWer<Pt>:ATTenuation:MODE AUTO | MANual | LNOise
Defines how the attenuation factor for the generated wave at test port no. <Pt> is set.
Use SOURce<Ch>:POWer<Pt>:ATTenuation to define a fixed (manual) generator attenuation factor.
<Ch>
Channel number.
<Pt>
Test port number of the analyzer.
Parameters
AUTO – automatic generator attenuator setting
MANual – manual entry of a fixed attenuation step
LNOise – Low noise mode (for measurements involving external power meters
with a wide bandwidth)
*RST value
AUTO
SCPI, Command
Types
Confirmed, command or query
Example:
See SOURce<Ch>:POWer<Pt>:ATTenuation
SOURce<Ch>:POWer<Pt>:GENerator<Gen>:LLIMit[:STATe] <Boolean>
Enables or disables the limit for the source power of an external generator no. <Gen>. The limit is defined
using SOURce<Ch>:POWer<Pt>:GENerator<Gen>:LLIMit:VALue.
<Ch>
Channel number. This suffix is ignored; the setting applies to all channels.
<Pt>
Test port number of the analyzer. This suffix is ignored; the generator is
selected via <Gen>.
<Gen>
Generator number
<Boolean>
ON | OFF: Enable or disable the power limit.
*RST value
The power limit settings are not changed after a *RST. The factory setting is
OFF.
SCPI, Command
Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>[:LEVel][:IMMediate]LLIMit:VALue
SOURce<Ch>:POWer<Pt>:GENerator<Gen>:LLIMit:VALue <limit>
Defines a limit for the source power of an external generator no. <Gen>. The limit must be enabled
explicitly using SOURce<Ch>:POWer<Pt>:GENerator<Gen>:LLIMit[:STATe].
<Ch>
Channel number. This suffix is ignored; the limit applies to all channels.
<Pt>
Test port number of the analyzer. This suffix is ignored; the generator is selected
via <Gen>.
<Gen>
Generator number
<limit>
Limit for the generator power.
Range [def. unit]
Depending on the generator model [dBm]. UP and DOWN increment/decrement
