<Ch>
Channel number.
<Pt>
Test port number of the analyzer. This suffix is ignored; the generator is
selected via <Gen>.
<Gen>
Generator number
<Boolean>
ON - Generator no. <Pt> is available.
OFF - Generator is available only if a measurement result with a generator drive
port is selected.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
SOUR:POW:GEN:PERM ON
Activate the generator as an external signal source.
SOURce<Ch>:POWer<Pt>:GENerator<Gen>:STATe <Boolean>
Turns an external generator numbered <Gen> on or off.
<Ch>
Channel number.
<Pt>
Test port number of the analyzer. This suffix is ignored; the generator is
selected via <Gen>.
<Gen>
Generator number
<Boolean>
ON | OFF - Generator is on or off
*RST value
ON
SCPI, Command
Types
Device-specific, command or query
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02', 'gpib0', '21'
Configure an R&S SME02 generator as external generator no. 1, assigning the
name Ext. Gen. 1 and a GPIB address 21.
SOUR:POW:GEN:STAT OFF
Turn the external generator off. In the Port Configuration dialog, RF Off is
checked for generator no. 1.
SOURce<Ch>:POWer<Pt>[:LEVel][:IMMediate][:AMPLitude] <power>
Defines the power of the internal signal source (channel base power). The setting is valid for all sweep
types except power sweep and segmented frequency sweep with segment-specific power settings
([SENSe<Chn>:]SEGMent<Seg>:POWer[:LEVel]).
