R&S ZVB - Page 968

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 953
[SENSe<Ch>:]SEGMent<Seg>:POWer[:LEVel] <Power>
Defines the Power of the internal signal source in sweep segment no. <Seg>. At the same time, the
command activates separate power control in all sweep segments
([SENSe<Ch>:]SEGMent<Seg>:POWer[:Level]:CONTrol ON).
<Ch>
Channel number
<Seg>
Sweep segment number
<Power>
Internal source power.
Range [def. unit]
–40 dBm to +10 dBm. The exact range depends on the analyzer model; refer
to the data sheet [dBm].
*RST value
–10 dBm.
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings and
thus –10 dBm internal source power.
SEGM:POW -20
Decrease the power to –20 dBm.
[SENSe<Ch>:]SEGMent<Seg>:POWer[:LEVel]:CONTrol <Boolean>
Selects common or independent internal source Power settings for the sweep segments.
<Ch>
Channel number
<Seg>
Sweep segment number. This suffix is ignored; the setting controls the whole
segmented sweep.
<Boolean>
ON: Use independent power settings, to be defined via
[SENSe<Ch>:]SEGMent<Seg>:POWer[:LEVel].
OFF: Reset the power in all sweep segments to the power for unsegmented sweeps,
defined via SOURce<Ch>:POWer[:LEVel][:IMMediate][:AMPlitude]. ON will
not restore the previous values.
*RST value
OFF. The parameter is automatically switched to ON when a segment power is
entered using [SENSe<Ch>:]SEGMent<Seg>:POWer[:LEVel].
SCPI,
Command
Types
Device-specific, command or query
Example:
SEGM:ADD
Create a new sweep segment no. 1 in channel no. 1 using default settings and thus –
10 dBm internal source power.
SEGM:POW -20
Decrease the power to –20 dBm.
SEGM:POW:CONT OFF
