R&S ZVB - Page 1023

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1008
Enables or disables the advanced power transfer model for the converter port <Pt>.
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
<Boolean>
ON | OFF - Enables or disables the advanced model.
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI,
Command
Types
Device-specific, command or query
Example:
SOUR:POW2:CONV:TRAN:AMOD ON; DESC LAPP
Enable the advanced power transfer model at the frequency converter port 2 and
select a linear approximation.
SOUR:POW2:CONV:TRAN:SLOP 1; OFFS 0
Define the slope and offset for the linear model with0 dB waveguide attenuators
setting.
SOUR:POW2:CONV:TRAN:ATT MECH
SOUR:POW2:CONV:TRAN:MECH:ATT 3
Select a converter type with a mechanical waveguide attenuator and define a 3-dB
attenuation
Alternatively....
SOUR:POW2:CONV:TRAN:ATT ELEC
SOUR:POW2:CONV:TRAN:ELEC:LIM -5; RED 50; MATT 20
Select a converter type with electronic attenuators and define a power threshold of
-5 dBm, 50 % power reduction due to the waveguide attenuator, and a maximum
attenuation of 20 dB.
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:ATTenuator MECHanical |
ELECtronic
Selects the waveguide attenuator type of the converter port <Pt>.
Since FW version 3.40 this is a global setting.
<Ch>
Channel number. This suffix is ignored, the command affects all channels.
<Pt>
Converter port number
Parameters
MECHanical - Adjustment screw (most converter models R&S ZVA-Zxxx)
ELECtronic - Electronic attenuator (converters R&S ZVA-ZxxxE only)
*RST value
n/a (a *RST does not affect the general frequency converter settings)
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:DESCription
