ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1007
for port <Pt> in channel <Ch>.
<Ch>
Channel number
<Pt>
Port number
<settling_tolerance>
Settling tolerance
Range [def. unit]
0.02 to 1.0 [dB]. Increment 0.01 dB.
*RST value
0.1 dB
SCPI, Command Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:ALC:AUBW
CONVerter
SOURce<Ch>:POWer<Pt>:CONVerter...
This subsystem provides general frequency converter settings.
SOURce<Ch>:POWer<Pt>:CONVerter:OFFSet <offset>, ONLY | CPADd
Defines a source power or a power offset relative to the channel power
(SOURce<Ch>:POWer<Pt>[:LEVel][:IMMediate][:AMPlitude]) for a frequency converter port
<Pt>. The command is available for converters with electronic attenuators (R&S ZVA-ZxxxE). An
additional Cal Power Offset can be defined via
SOURce<Ch>:POWer<Pt>:CORRection:LEVel:OFFSet.
<Ch>
Channel number
<Pt>
Converter port number
<offset>
Port-specific power offset
Range [def. unit]
–300 dB to +300 dB [dB]. UP and DOWN increment/decrement the phase in
1-dB steps.
*RST value
0 dB
Offset parameters
ONLY – only the port-specific power is used; the channel power is ignored.
CPADd – the port-specific power is added as an offset to the channel power.
*RST value
CPADd
SCPI, Command
Types
Device-specific, command or query
Example:
See SOURce<Ch>:FREQuency<Pt>:CONVersion:ARBitrary:CFRequency
SOURce<Ch>:POWer<Pt>:CONVerter:TRANsfer:AMODel <Boolean>
[Deprecated command, superseded by
SOURce<Ch>:POWer<Port>:CONVerter:TRANsfer:DESCription]
