SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1014
Perform a source power calibration using port 1 as a source port.
SOUR:POW:CORR:STAT?
Check whether the calibration is applied (if no error occurred during the
calibration sweep, the response is 1).
SENSe:CORRection:PSTATe?
Query the power calibration state label (if no error occurred during the calibration
sweep, the response is 'Pcal').
Change the test setup, connect an external generator no. 1 to the reference
plane.
SOUR:POW:CORR:ACQ GEN,1
Perform a source power calibration using the external generator no. 1 as a
source.
SOUR:POW:CORR:GEN?
Check whether the calibration is applied (if no error occurred during the
calibration sweep, the response is 1).
Example 2:
Suppose that an external frequency converter with electronic attenuator is
connected to port 1 of the analyzer and that the instrument is configured for
frequency converter measurements.
SOUR:POW:CORR:ACQ CONV,1
Perform a source power calibration using the external converter no. 1 as a
source.
SOUR:POW:CORR:CONV?
Check whether the calibration is applied (if no error occurred during the
calibration sweep,(the response is 1).
SOURce<Ch>:POWer<Pt>:CORRection[:ACQuire]:VERification:RESult?
Returns the result of the last verification sweep. This command requires an enabled verification sweep
(SOURce<Ch>:POWer<Pt>:CORRection:COLLect[:ACQuire]:VERification[:STATe] ON, see
example below).
<Ch>
Calibrated channel number. This suffix is ignored; the result is based on the last
verification sweep acquired.
<Pt>
Calibrated port number. This suffix is ignored; the result is based on the last
verification sweep acquired.
Response:
Result of the sweep in the format <Boolean>, <Max. Offset> where:
<Boolean>
Calibration passed, i.e. the cal. power offset is below the tolerance (1), or failed
(0).
<Max. Offset>
Maximum power offset between the measured power at the reference plane and
the Cal Power during the verification sweep in dB.
*RST value
–
If no verification sweep result is available, the command returns 0.
