SCPI, Command
Types
Device-specific, command or query
Example:
*RST; SOUR:POW:CORR:COLL:VER ON
Enable the verification sweep.
SOUR:POW:CORR:NRE 2; COLL:AVER:NTOL 0.5
Increase the number of readings and reduce the power tolerance to improve the
accuracy.
SOUR:POW:CORR:ACQ PORT,1
Perform a source power calibration using port 1 as a source port.
SOUR:POW:CORR:COLL:VER:RES?
Query the result of the verification sweep.
SOURce<Ch>:POWer<Pt>:CORRection:COLLect[:ACQuire] ASENsor | BSENsor
Initiates a source power calibration for the source port <Pt> using an external power meter no. 1 or 2. To
initiate a source power calibration for arbitrary power meters, use the alternative commands listed in the
program example below.
The command cannot be used unless a power meter is connected via GPIB bus, USB or LAN
interface and configured in the External Power Meters dialog.
<Ch>
Calibrated channel number
<Pt>
Calibrated port number.
ASENsor |
BSENsor
External power meter Pmtr 1
External power meter Pmtr 2
*RST value
ASENsor
SCPI, Command
Types
Device-specific, no query
Example:
SOUR:POW3:CORR:COLL BSEN
Perform a source power calibration for port 3 using power meter no. 2.
SOUR:POW:CORR:PMET:ID 2
Select power meter no. 2.
SOUR:POW:CORR:ACQ PORT,3
Perform a source power calibration for port 3 using the previously selected
power meter no. 2.
SOURce<Ch>:POWer<Pt>:CORRection:COLLect[:ACQuire]:VERification[:STATe]
<Boolean>
Enables or disables a verification sweep that the analyzer performs after the source power calibration. The
command is valid for all channels, ports and external generators.
