SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1021
Perform a source power calibration using port 1 as a source port.
SOUR:POW:CORR:DATA? 'A1'
Query the correction values. The analyzer returns 10 comma-separated
real numbers.
SOUR:POW:CORR:DATA 'A1', 1, 2, 3, 4, 5, -6, -7, -8, -9, -0
Replace the correction values by ten (new) numbers.
SOURce<Ch>:POWer<Pt>:CORRection:DATA:PARameter<Cal_index>? <info>
Returns the sweep settings of the active source and receiver power calibrations for channel <Ch>.
<Ch>
Calibrated channel number
<Pt>
Calibrated port number. This parameter is ignored; the port is identified by the
<Cal_index> suffix.
<Cal_index>
Current number of calibrated a-wave or b-wave (for receiver power
calibration).
<info>
Parameter to specify the information retrieved; see table below.
*RST value
n/a (the command generates an execution error if no power calibration is
active)
SCPI, Command
Types
Device-specific, query only
Example:
*RST; :SWE:POIN 10
SOURce:POWer:CORRection:DEFault ON
SOURce:POWer:CORRection:ACQuire PORT,1
Perform a dummy source power calibration at port 1 (no external power meter
required).
SOURce:POWer:CORRection:DATA:PARameter:COUNt?
Query the number of calibrated waves. The response is 1.
SOURce:POWer:CORRection:DATA:PARameter1? WAVE
Query the first calibrated wave. The response is a1 Gen (source power
calibration).
SOURce:POWer:CORRection:DATA:PARameter2? WAVE
Query the first calibrated wave. The response is a1 Rec (reference receiver
calibration).
Optional parameters of SOURce<Ch>:POWer<Pt>:CORRection:DATA:PARameter<Wave>?
Parameter
<info>
Response
WAVE
Calibrated wave: a1 Gen denotes the source power at port 1, Ext Gen1 the source power of an external
generator, a1 Rec or b1 Rec the receiver power at port 1 etc.
STARt
Start frequency or power (or CW frequency, if no frequency or power sweep is active)
