R&S ZVB - Page 1053

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 1038
<Pt>
Calibrated port number. This parameter is ignored; the transmission coefficient
settings are valid for all sources.
'<trace_name>'
String parameter for the trace name, e.g. 'Trc1'. The trace must exist in the
active setup.
*RST value
n/a
SCPI, Command
Types
Device-specific, no query
Example:
See SOURce<Ch>:POWer<Pt>:CORRection:TCOefficient:CALibration
SOURce<Ch>:POWer<Pt>:CORRection:TCOefficient:INSert<List_No>
<frequency>, <transmission>
Inserts a new frequency and transmission coefficient at position no. <List_no> in the power loss list. The
following points are shifted down in the list.
<Ch>
Calibrated channel number. This parameter is ignored; the transmission
coefficient settings are valid for all channels.
<Pt>
Calibrated port number. This parameter is ignored; the transmission coefficient
settings are valid for all sources.
<List_no>
Number of inserted point in the list.
<frequency>
Stimulus frequency value
Range [def. unit]
Stimulus values outside the frequency range of the analyzer are allowed [Hz]. If
several points with identical frequencies are added, the analyzer automatically
ensures a frequency spacing of 1 Hz.
<transmission>
Transmission coefficient
Range [def. unit]
–300 dB to +200 dB [dB]
*RST values
n/a
SCPI, Command
Types
Device-specific, command or query.
Example:
See SOURce<Ch>:POWer<Pt>:CORRection:TCOefficient:CALibration
SOURce<Ch>:POWer<Pt>:CORRection:TCOefficient[:STATe] <Boolean>
Enables or disables the use of two-port transmission coefficients.
The power loss list must contain at least one point before the transmission coefficients can be
enabled.
<Ch>
Calibrated channel number. This parameter is ignored; the transmission
coefficient settings are valid for all channels.
<Pt>
Calibrated port number. This parameter is ignored; the transmission coefficient
settings are valid for all sources.
<Boolean>
Enables (ON) or disables (OFF) the two-port transmission coefficients.
*RST value
OFF [–]
