center of the bandstop region.
CALC:MARK:FUNC:EXEC BFIL
Initiate the bandpass filter search for the current trace. Create markers 1 to 4.
CALC:MARK:SEAR:BFIL:RES ON
Display the marker info field in the diaram area.
CALC:MARK:BWID 6
Select a 6-dB bandwidth for the bandstop.
CALC:MARK:BWID?
Query the results of the bandfilter search. An error message is generated if
the bandfilter search fails so that no valid results are available.
CALCulate<Chn>:MARKer<Mk>:COUPled[:STATe] <Boolean>
Couples the markers of all traces in the active setup to the markers of trace no. <Chn>, provided that they
have the same sweep type (SENSe<Chn>:FUNCtion).
<Chn>
Channel number used to identify the active trace. The effects of marker coupling
depend on the active trace number; see Coupled Markers in the GUI Reference
chapter.
<Mk>
Marker number in the range 1 to 10. This suffix is ignored because the command
affects all markers.
<Boolean>
ON | OFF - Enables or disables marker coupling.
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query.
Example:
Suppose that the active setup contains two traces Trc1 and Trc2, assigned to
channels no. 1 and 2, respectively.
:CALC1:PAR:SEL 'TRC1'; :CALC1:MARK1 ON; MARK2 ON
Select Trc1 as the active trace and create the two markers no. 1 and 2. The
default position for both markers is the center of the sweep range.
CALC1:MARK:COUP ON
Create two markers no. 1 and 2 on Trc 2 and couple them to the markers of Trc 1.
CALCulate<Chn>:MARKer<Mk>:DELTa[:STATe] <Boolean>
Switches the delta mode for marker <Mk> on trace no. <Chn> on or off. The marker must be created
before using CALCulate<Chn>:MARKer<Mk>[:STATe] ON. If the active trace contains no reference
marker, the command also creates a reference marker.
<Chn>
Channel number used to identify the active trace.
