R&S ZVB - Page 674

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 659
for marker no. 1.
CALC:MARK:SEAR:TRAC ON
Enable the tracking mode for the created marker.
CALCulate<Chn>:MARKer<Mk>[:STATe] <Boolean>
Creates the marker numbered <Mk> and assigns it to trace no. <Chn>.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. If unspecified the numeric suffix is set to
1.
<Boolean>
ON | OFF - Creates or removes the marker.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query
Example:
Suppose that the active setup contains an active trace no. 1.
CALC:MARK ON; MARK2 ON
Create markers 1 and 2 and assign them to trace no. 1. The default position of both markers is
the center of the sweep range.
CALCulate<Chn>:MARKer<Mk>:TARGet <search_value>
Defines the target value for the target search of marker no. <Mk>, which can be activated using
CALCulate<Chn>:MARKer<Mk>:FUCTion:EXECute TARGet.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10
<search_value>
Target search value of marker no. <Mk>
Range [def. unit]
Depending on the format of the active trace (CALCulate<Chn>:FORMat). For
a dB Mag trace the range is –300 dB to +200 dB, the increment (UP. DOWN) is
0.1 dB. [dB, deg etc., depending on the trace format]
*RST value
Depending on the trace format; 0 dB for a dB Mag trace
SCPI, Command
Types
Device-specific, command or query
Example:
CALC:MARK ON
Create marker no. 1 and display it in the center of the sweep range.
:CALC:MARK:TARG -10; FUNC:EXEC TARG
Define a target search value of –10 dB and start the target search.
CALC:MARK:X?
Query the stimulus value corresponding to the target search result.
