R&S ZVB - Page 661

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 646
SCPI,
Command
Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:MARKer<Mk>:BWIDth.
CALCulate<Chn>:MARKer<Mk>:FUNCtion:BWIDth:MODE BPASs | BSTop |
BPRMarker | BSRMarker | BPABsolute | BSABsolute
Selects the bandfilter search mode.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10. This numeric suffix is ignored and may be set
to any value because the bandfilter search functions always use markers M 1 to M
4.
Parameters
Bandfilter search type:
BPASs: Bandpass Search Ref to Max
BSTop: Bandstop Search Ref to Max
BPRMarker: Bandpass Search Ref to Marker
BSRMarker: Bandstop Search Ref to Marker
BPABsolute: Bandpass Absolute Level
BSABsolute: Bandstop Absolute Level
*RST value
BPASs
SCPI,
Command
Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:MARKer<Mk>:BWIDth.
CALCulate<Chn>:MARKer<Mk>:FUNCtion:CENTer
Sets the center of the sweep range equal to the stimulus value of the marker <Mk> on trace no. <Chn>.
<Chn>
Channel number used to identify the active trace
<Mk>
Marker number in the range 1 to 10
Range [def. unit]
– [–]
*RST value
–
SCPI, Command
Types
Device-specific, no query.
Example:
*RST; :CALC:MARK ON
Create marker 1 in the center of the current sweep range and assign it to
trace no. 1.
CALC:MARK:FUNC:CENT
Leave the sweep range unchanged.
