R&S ZVB - Page 677

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 662
Define a mathematical trace, dividing the data trace by the stored memory trace.
The mathematical trace is not displayed
CALC:MATH:STAT ON
Display the mathematical trace instead of the active data trace.
CALCulate<Chn>:MATH[:EXPRession]:SDEFine '<string>'
Defines a general mathematical relation between traces. To calculate and display the new mathematical
trace, the mathematical mode must be switched on (CALCulate<Chn>:MATH:STATe ON).
<Chn>
Channel number used to identify the active trace.
'<string>'
String parameter for the mathematical expression, enclosed in brackets. The string
format must correspond to an allowed string in the Define Math dialog.
Parameters
Operands, operators and functions; see table below.
*RST value
–
SCPI,
Command
Types
Device-specific, command or query. This command also queries a mathematical
expression defined via CALCulate<Chn>:MATH[:EXPRession][:DEFine].
Example:
*RST; :CALC:MATH:MEM
Copy the current state of the default trace Trc1 to a memory trace named
'Mem2[Trc1]'. The memory trace is not displayed.
CALC:MATH:SDEF 'Trc1 / Mem2[Trc1]'
Define a mathematical trace, dividing the data trace by the stored memory trace.
The mathematical trace is not displayed.
CALC:MATH:STAT ON
Display the mathematical trace instead of the active data trace.
Expressions defined via CALCulate<Chn>:MATH[:EXPRession]:SDEFine may contain the following
elements:
Type
Complete List
Description
Operands
<Trace name> |
activeTrc |
Mem[activeTrc]
All traces and memory traces of the active setup |
Active trace |
Active memory trace assigned to the active trace
Constants
e, pi |
1, -1.2, 8e9 |
1 + 2j, 2 + 1e-9j
Constants |
Real values in decimal or exponential format |
Complex numbers
Operators
- + , - , * , / , ^
Basic arithmetic operations; ^ for exponentiation
Functions
linMag (), dBMag (), Arg (), Re (), Im (), log (), ln (), tan (),
atan (), sin (), asin (), cos (), acos (),
Min ( ... , ... ), Max ( ... , ... )
Mathematical functions with one or two
arguments
Special
Functions
StimVal
Current stimulus value (see description of
operators for User Defined Math)
