R&S ZVB - Page 679

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 664
TRACe:COPY:MATH <memory_trc>,<data_trc>
<Chn>
Channel number used to identify the active trace.
*RST value
–
SCPI, Command
Types
Device-specific, no query
Example:
*RST; :CALC:MATH:MEM
Copy the current state of the default trace Trc1 to a memory trace named
'Mem2[Trc1]'. The memory trace is not displayed.
DISP:WIND:TRAC2:FEED 'Mem2[Trc1]'
Display the created memory trace in the active diagram area (diagram area no.
1).
CALCulate<Chn>:MATH:STATe <Boolean>
Activates or deactivates the mathematical mode where the mathematical trace defined via
CALCulate<Chn>:MATH[:EXPRession]:SDEFine is calculated and displayed instead of the active
data trace. The command is not valid for mathematical traces calculated via
CALCulate<Chn>:MATH:FUNCtion.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON - Display the active data trace
OFF - Display the mathematical trace
*RST value
OFF
SCPI, Command
Types
Confirmed, command or query.
Example:
*RST; :CALC:MATH:MEM
Copy the current state of the default trace Trc1 to a memory trace named
'Mem2[Trc1]'. The memory trace is not displayed.
CALC:MATH:SDEF 'Trc1 / Mem2[Trc1]'
Define a mathematical trace, dividing the data trace by the stored memory
trace. The mathematical trace is not displayed
CALC:MATH:STAT ON
Display the mathematical trace instead of the active data trace.
CALCulate<Chn>:MATH:WUNit[:STATe] <Boolean>
Controls the conversion and formatting of the mathematic expression defined via
CALCulate<Chn>:MATH[:EXPRession]:SDEFine (see Result is Wave Quantity in the User Def Math
dialog).
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON - Result is Wave Quantity enabled; the analyzer assumes that the result of the
mathematical expression represents a voltage.
