OFF - Result is Wave Quantity disabled; the analyzer assumes that the result of
the mathematical expression is dimensionless.
*RST value
OFF
SCPI,
Command
Types
Device-specific, command or query.
Example:
*RST; SWE:TYPE POW
Reset the instrument, activate a power sweep, and select a wave quantity a1 for
the trace Trc1.
CALC:PAR:SDEF 'Trc1', 'a1'
Select a wave quantity a1 for the trace Trc1.
DISP:WIND:TRAC:FEED 'Trc1'
Display the generated trace in the active window.
CALC:MATH:SDEF 'StimVal'; STAT ON
Define a mathematical trace, dividing the data trace by the stored memory trace.
Display the mathematical trace instead of the active data trace.
CALC:MATH:WUN ON
Take into account that the stimulus value is a voltage (derived from the source
power) rather than a dimensionless quantity. The y-axis range of the mathematical
trace now exactly corresponds to the power sweep range.
CALCulate<Ch>:PARameter...
This subsystem assigns names and measured quantities to traces. The commands are device-specific.
CALCulate<Ch>:PARameter:CATalog?
Returns the trace names and measured quantities of all traces assigned to a particular channel.
<Ch>
Channel number. If unspecified the numeric suffix is set to 1.
Response
String parameter with comma-separated list of trace names and measured quantities,
e.g. 'CH4TR1,S11,CH4TR2,S12'. The measured quantities are returned according
to the naming convention of CALCulate<Ch>:PARameter:SDEFine. The order of
traces in the list reflects their creation time: The oldest trace is the first, the newest
trace is the last trace in the list.
*RST value
–
SCPI,
Command
Types
Device-specific, query only.
Example:
CALC4:PAR:SDEF 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S11.
