Example:
CALCulate4:PARameter:SDEFine 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the input reflection
coefficient S
11
.
CALCulate4:PARameter:CATalog?
Query the traces assigned to channel 4. If Ch4Tr1 is the only trace assigned to
channel 4, the response is 'CH4TR1,S11'.
CALCulate4:PARameter:SDEFine 'CH4TR2', 'S21'; SDEFine 'CH4TR3', 'S12'; SDEFine 'CH4TR4',
'S22'
Create three more traces for the remaining 2-port S-parameters.
CALCulate4:PARameter:DELete 'CH4TR1'
Delete the first created trace.
CALCulate4:PARameter:DELete:CALL
Delete the remaining three traces in channel 4.
CALCulate:PARameter:DELete:ALL
Delete all traces, including the default trace Trc1 in channel 1.
CALCulate<Ch>:PARameter:DELete:ALL
Deletes all traces in all channels of the active setup, including the default trace Trc1 in channel no. 1. The
manual control screen shows "No Trace".
<Ch>
Channel number. This suffix is ignored, the command affects all channels in the
active setup. To delete all traces in a channel, use
CALCulate<Ch>:PARameter:DELete:CALL.
SCPI,
Command
Types
Device-specific, no query.
Example:
See CALCulate<Ch>:PARameter:DELete
CALCulate<Ch>:PARameter:DELete:CALL
Deletes all traces in channel no. <Ch>.
<Ch>
Channel number
SCPI, Command Types
Device-specific, no query.
Example:
See CALCulate<Ch>:PARameter:DELete
CALCulate<Ch>:PARameter:DELete:SGRoup
Deletes a group of logical ports (S-parameter group), previously defined via
CALCulate<Ch>:PARameter:DEFine:SGRoup.
