R&S ZVB - Page 688

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 673
'AP1G2' | ... | 'AP01G02' | ... |
'BP1G2' | ... | 'BP01G02' | ... |
'AP1G1SAM' | 'AP1G1RMS' |
'AP1G1PEAK' | 'AP1G1AVG' | ...
Primed wave quantities, e.g. for mixer delay measurements, with port numbers and
external generator providing the stimulus signal (G<no> for generator no.). The
strings SAM, RMS, PEAK, AVG appended to the wave quantities denote a normal
(sample), RMS, peak, or average detector.
'AS1D2S' | ... | 'AS1D2C' | ... '
'BS1D2S' | 'AS1D2SSAM' |
'AS1D2SRMS' | 'AS1D2SPEAK' |
'AS1D2SAVG' | ...
Balanced (D, C) or single-ended (S) wave quantities with port numbers and source
port numbers (D<no> for drive port) in true differential mode (option R&S ZVA-K6).
The strings SAM, RMS, PEAK, AVG appended to the wave quantities denote a
normal (sample), RMS, peak, or average detector.
'APS1D2S' | ... | 'APS1D2C' | ...
| 'BPS1D2S' | 'APS1D2SSAM' |
'APS1D2SRMS' | 'APS1D2SPEAK' |
'APS1D2SAVG' | ...
Primed balanced (D, C) or single-ended (S) wave quantities with port numbers and
source port numbers (D<no> for drive port) in true differential mode (option R&S
ZVA-K6). The strings SAM, RMS, PEAK, AVG appended to the wave quantities
denote a normal (sample), RMS, peak, or average detector..
'B2/A1' | ... 'B02/A01' | ... |
'B2/A1SAM' | 'B2/A1RMS' |
'B2/A1PEAK' | 'B2/A1AVG' | ...
Ratio of wave quantities with port numbers like for normal mode S-parameters, but
with port 1 as driving port. The strings SAM, RMS, PEAK, AVG appended to the
wave quantities denote a normal (sample), RMS, peak, or average detector.
'BP2/A1' | ... 'BP02/A01' | ... |
'BP2/A1SAM' | 'B2/AP1RMS' |
'B2/AP1PEAK' | 'B2/AP1AVG' | ...
Ratio of primed/unprimed wave quantities with port numbers like for normal mode S-
parameters. The strings SAM, RMS, PEAK, AVG appended to the wave quantities
denote a normal (sample), RMS, peak, or average detector.
'B2D1/A1D1' | ... 'B02D01/A01D01'
| ... 'B2D1/A1D1SAM' |
'B2D1/A1D1RMS' | 'B2D1/A1D1PEAK'
| 'B2D1/A1D1AVG' | ...
Ratio of wave quantities with port numbers and source port numbers (D<no> for
drive port). The strings SAM, RMS, PEAK, AVG appended to the wave quantities
denote a normal (sample), RMS, peak, or average detector.
In contrast to manual control, different drive ports for numerator and denominator
wave quantity are allowed.
'BP2D1/A1D1' | ...
'BP02D01/A01D01' | ...
'BP2D1/A1D1SAM' | 'B2D1/AP1D1RMS'
| 'BP2D1/AP1D1PEAK' |
'BP2D1/AP1D1AVG'...
Ratio of primed/unprimed wave quantities with port numbers and source port
numbers (D<no> for drive port). The strings SAM, RMS, PEAK, AVG appended to
the wave quantities denote a normal (sample), RMS, peak, or average detector.
In contrast to manual control, different drive ports for numerator and denominator
wave quantity are allowed.
'B2G1/A1G1' | ... 'B02G01/A01G01'
| ... 'B2G1/A1G1SAM' |
'B2G1/A1G1RMS' | 'B2G1/A1G1PEAK'
| 'B2G1/A1G1AVG' | ...
Ratio of wave quantities with port numbers and external generator providing the
stimulus signal (G<no> for generator no.). The strings SAM, RMS, PEAK, AVG
appended to the wave quantities denote a normal (sample), RMS, peak, or average
detector.
'BP2G1/A1G1' | ... 'BP02G1/A01G1'
| ... 'B2G1/AP1G1SAM' |
'B2G1/AP1G1RMS' |
'BP2G1/AP1G1PEAK' |
'BP2G1/AP1G1AVG' | ...
Ratio of primed/unprimed wave quantities with port numbers and external generator
providing the stimulus signal (G<no> for generator no.). The strings SAM, RMS,
PEAK, AVG appended to the wave quantities denote a normal (sample), RMS,
peak, or average detector.
'BD1D1D/AD1D1D' | ... |
'BD1D1D/AD1D3S' |
'BD1D1D/AD1D3SSAM' |
'BD1D1D/AD1D3SRMS' |
'BD1D1D/AD1D3SPEAK' |
'BD1D1D/AD1D3SAVG' | ...
Ratio of balanced (D, C) or single-ended (S) wave quantities with port numbers and
source port numbers (D<no> for drive port) in true differential mode (option R&S
ZVA-K6). The strings SAM, RMS, PEAK, AVG appended to the wave quantities
denote a normal (sample), RMS, peak, or average detector.
In contrast to manual control, different drive ports for numerator and denominator
wave quantity are allowed.
'BPD1D1D/AD1D1D' | ... |
'BPD1D1D/AD1D3S' |
'BD1D1D/APD1D3SSAM' |
'BD1D1D/APD1D3SRMS' |
'BPD1D1D/APD1D3SPEAK' |
'BPD1D1D/APD1D3SAVG' | ...
Ratio of primed/unprimed balanced (D, C) or single-ended (S) wave quantities with
port numbers and source port numbers (D<no> for drive port) in true differential
mode (option R&S ZVA-K6). The strings SAM, RMS, PEAK, AVG appended to the
wave quantities denote a normal (sample), RMS, peak, or average detector.
In contrast to manual control, different drive ports for numerator and denominator
wave quantity are allowed.
'IMB21' | 'IMB12' | 'IMB31' | ...
Imbalance parameter for balanced ports Imb<receive_port><drive_port>. The
indices denote the logical receive port and the logical drive port of the analyzer.
