'KFAC21' | 'KFAC12' | ...
Stability factor K (for unbalanced ports only)
'MUF121' | 'MUF112' | ...
Stability factor μ
1
(for unbalanced ports only)
'MUF221' | 'MUF212' | ...
Stability factor μ2 (for unbalanced ports only)
'PAE21' | PAE12' | ...
Power added efficiency
'DC1V' | 'DC10V'
(query returns 'DC 1V' or 'DC
10V')
DC MEAS –1 V...+1 V, DC MEAS –10 V...+10 V
'Pmtr1G1' | 'Pmtr2G1' | 'Pmtr3D1'
| ...
Power sensor measurement using a power meter 'Pmtr<no>' and either an external
generator 'G<no>' or an analyzer source port 'D<n>'
'IM3UI' | 'IM3UO' | 'IM3LI' |
'IM3LO' | 'IM3MI' | 'IM3MO' |
'IM5UI' ... 'IM9MO
Intermodulation product IM<order><side><at DUT> where <order> = 3 | 5 | 7 | 9,
<side> = U | L | M (for upper or lower or major), <at DUT> = I | O (for input or
output)
'IP3UI' | 'IP3UO' | 'IP3LI' |
'IP3LO' | 'IP3MI' | 'IP3MO' |
'IP5UI' ... 'IP9MO
Intercept point IP<order><side><at DUT> where <order> = 3 | 5 | 7 | 9, <side> = U |
L | M (for upper or lower or major), <at DUT> = I | O (for input or output)
'NLO'
Noise level at DUT output
'MIXDLY' | 'MIXDERIV' | 'MIXPHAS'
Mixer delay, mixer derivative, mixer phase (with options R&S ZVA-K4 and R&S
ZVA-K9)
'S21I' | 'S21IAVG' ...
'A1D1ISAM' | 'A1D1IAVG' ...
'B2D1ISAM' | 'B1D1IAVG' ...
Image conversion gain (scalar mixer measurements)
a drive port image
b receive port image
'UTI' | 'UTO' | 'LTI' | 'LTO'
Upper or lower tone at DUT input or output
'NF11' | 'NF12' | ... | 'NF0101'
| ...
Noise Figure parameters NF<out><in>, where <out> and <in> denote the output
and input port numbers of the DUT. To avoid ambiguities, <out> and <in> must be
either both 1-digit numbers (e.g. 21) or both 2-digit numbers (e.g. 2121 or 0133).
*
)
Selecting a parameter Y...<n><m> or Z...<n><m> sets the range of port numbers to be considered for
the Y and Z-parameter measurement to <n>:<m>.
The available measured quantities depend on the available ports: e.g. S44 is not available on 2-port
analyzers.
CALCulate<Ch>:PARameter:SELect <string>
Selects an existing trace as the active trace of the channel. All trace commands without explicit reference
to the trace name act on the active trace (e.g. CALCulate<Chn>:FORMat).
CALCulate<Ch>:PARameter:SELect is also necessary if the active trace of a channel has been
deleted.
<Ch>
Channel number.
<string>
Trace name, e.g. 'Trc4'. See Rules for trace names in the Trace Manager
description.
*RST value
–
