You can display or hide the Min/Max/Peak-Peak, Mean/Std Dev, RMS, Phase Delay/El Length and
Gain/Slope/Flatness results separately; see example below.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - Statistical info field on or off.
*RST value
OFF
SCPI, Command
Types
Device-specific, command or query.
Example:
*RST; :CALC:STAT:MMPT ON
Reset the instrument, hiding all statistical results. Display the Min/Max/Peak-
Peak results.
CALC:STAT:MSTD ON
Display the Mean/Std Dev results in addition.
CALC:STAT:RMS ON
Display the RMS results in addition.
CALC:STAT:EPD ON
Display the Phase Delay/El Length results in addition.
CALC:STAT:SFL ON
Display the Gain/Slope/Flatness results in addition.
CALC:STAT OFF
Hide all results.
CALCulate<Ch>:TDIF...
This subsystem provides settings for the True Differential Mode (with option R&S ZVA-K6).
CALCulate<Ch>:TDIF:IMBalance:COMPensation[:STATe] <Boolean>
Selects the calculation method for S-parameters, ratios and derived quantities during an amplitude
imbalance or phase imbalance sweep.
<Ch>
Channel number
<Boolean>
ON – Compensate imbalance of a waves
OFF – Use the actual a-waves, depending on the imbalance parameters
*RST value
OFF [–]
SCPI, Command Types
Device-specific, command or query
Example:
See SOURce<Ch>:TDIF:IMBalance:AMPLitude:LPORt
