R&S ZVB - Page 703

R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT Command Reference
SCPI Command Reference
Operating Manual 1145.1084.12 – 30 688
CALCulate<Ch>:PARameter:SDEFine but also depends on the trace format
(linear or logarithmic scale, see CALCulate<Chn>:FORMat). If a polar trace format
is selected, then the statistical parameters are calculated from the linear magnitude
of the measurement parameter. [–]
*RST value
–
SCPI,
Command
Types
Device-specific, query only.
Example:
*RST; :CALC:STAT:RES? MAX
Calculate and return the maximum of the default trace showing an S-parameter on a
dB Mag scale.
:CALC:FORM POL; STAT:RES? MAX
Display the trace in a polar diagram and re-calculate the maximum. The result
corresponds to the previous result but is converted to a unitless linear value.
CALCulate<Chn>:STATistics:RMS[:STATe] <Boolean>
Displays or hides the RMS results in the diagram area of trace no. <Chn>.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - Statistical info field on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:STATistics:[:STATe]
CALCulate<Chn>:STATistics:SFLatness[:STATe] <Boolean>
Displays or hides the Gain/Slope/Flatness results in the diagram area of trace no. <Chn>.
<Chn>
Channel number used to identify the active trace.
<Boolean>
ON | OFF - Statistical info field on or off.
*RST value
OFF
SCPI, Command Types
Device-specific, command or query.
Example:
See CALCulate<Chn>:STATistics:[:STATe]
CALCulate<Chn>:STATistics[:STATe] <Boolean>
Displays or hides all statistical results in the diagram area of trace no. <Chn> except the compression
point results.
